CCD detection system for slitting machine
Overview
Application: Appearance detection system for winding machine, uses CCD to take real-time photos of electrode surface to achieve detection of winding alignment, tab folding, dislocation of tabs at the unloading station, and etc. Detection Items： ①Flaw detection ②Upper and down surfaces alignment detection ③Tab folding ④Tab dislocation
Get a Quote →Details & Specs
Application: Appearance detection system for winding machine, uses CCD to take real-time photos of electrode surface to achieve detection of winding alignment, tab folding, dislocation of tabs at the unloading station, and etc.
Detection Items：
①Flaw detection
②Upper and down surfaces alignment detection
③Tab folding
④Tab dislocation
Product drawing：
Winding machine display image：
1、Detection Content
① Defects Detection
② Top and Bottom Surfaces Alignment Detection
③ Tab Die Cutting Inspection
④ Appearance Inspectionn
Technical parameter：
| Cell size | 250mm |
| Coating process | 连续涂布 Continuous coating |
| Detection speed | ≤3000mm/s |
| Detection accuracy | ±0.1mm |
| Camera | Line scan 4K/Area-array500W |
| Misjudgment rate | Detect rate99.9%, false rejection≤0.1% |
| Undetected rate | 0 |
| GRR | ≤10% |
| NDC | ≥5% |
| CPK | ≥1.67 |
